Axis S3016 8 TB Network Video Recorder and 16-Port PoE Switch - 02527-004

Axis S3016 is a powerful solution for network video security that combines a 16-channel network video recorder (NVR) and 16-port PoE network switch. As a recorder, S3016 uses four surveillance-grade hard drives. It supports RAID Levels 0, 1, 5, 6, and 10. It has a 2.5-Gigabit uplink, which means it can handle even 4K Ultra HD resolution video. The video is encrypted via the TPM 2.0 (Trusted Platform Module) and S3016 supports secure access to the video via Axis Secure Remote Access.

S3016 is also a PoE switch with 16 Gigabit Ethernet ports and a total power budget of 305 W. It is compatible with up to 802.3at Class 4 PoE, so it can deliver the power your cameras and other surveillance devices need. Use this two-in-one video surveillance solution for single-site systems, multi-site systems, or to expand existing systems. S3016 is intended for mounting in a standard 1U rack or for table-mounting.

Note: This model of Axis S3016 (02527-004) comes with 8 TB of HDD storage. S3016 is also available with 16 TB (02351-004) or 32 TB (02352-004) of HDD storage.

© 2025 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis S3016 8 TB Quick Specs:

• Storage: 8 TB HDD (4 x 2 GB)
• Supported RAID Levels: 0, 1, 5, 6, 10
• System on Chip (SoC): i.MX 8QuadMax
• Channels: up to 16 video sources
• Recording Rate: up to 256 Mbit/sec
• Video Compression: H.264 (AVC), H.265 (HEVC)
• Physical Connectors (Rear):
• PoE: 16x Gigabit RJ45 PoE
• AUX: 1x 2.5-Gigabit RJ45
• LAN: 1x 2.5-Gigabit RJ45, 1x SFP Gigabit
• USB: 1x USB-A 2.0
• Power: 1x power connector
• Physical Connectors (Front): 1x USB-A 3.0
• PoE Power Budget: 305 W

Axis S3016 Recorder/PoE Switch Package Contents:

• NVR
• Rack Rails
• Front Cover
• Rubber Feet
• Installation Guide
• Power Cord
• Screws

Axis S3016 Documentation:

• Axis S3016 Datasheet
• Axis S3016 Installation Guide
