Axis T94Q01A Aluminum Fixed Camera Wall Mount - 5505-241

The Axis T94Q01A Wall Mount provides you with a steady pan-and-tilt mounting option for Axis IP cameras. It's not only compatible with a wide range of cameras, but also with Axis fixed housings, which increase your options for placement and the protection your network surveillance cameras receive. It is NEMA 4X rated for corrosion resistance and IK10 rated for impacts.

Axis 5505-241 routes the Ethernet cable internally through the robust aluminum wall mount. The camera is mounted securely on a pan-and-tilt head, so you'll be able to position the camera to your precise requirements.

Use with Axis T94R01P Conduit Back Box to expand your options.

Axis T94Q01A Wall Mount Quick Specs:

• Compatibility:
  • Axis P13-E network cameras
  • Axis Q16-E network cameras
  • Axis Q1755-E network camera
  • Axis Q1910-E/Q1921-E/Q1922-E thermal network cameras
  • Axis T91A47 pole mount
  • Axis T92E housing series
  • Axis T93E05 protective housing
  • Axis T93F housing series
  • Axis T94R01P conduit back box
  • Axis T98A16-VE surveillance cabinet
• Angle:
  • Tilt: +25° to -65°
  • Pan: +100° to -100°
• Environment: indoor or outdoor
• Compliance: RoHS, REACH, CE
• Maximum Load: 13.3 lbs.
• Material: powder coated aluminum

Axis 5505-241 Wall Mount Package Contents:

Note: Requires Torx 30 bit for installation (not included)

• Axis T94Q01A wall mount
• Installation guide
