Viking E-75-SS-EWP Stainless Entry Phone Card Reader & Camera with EWP

The Viking E-75-SS-EWP is an all-in-one phone, camera, and card reader featuring Viking’s Enhanced Weather Protection (EWP) and is perfect to screen people coming and going from your home or office. Compact and durable, the stainless-steel box provides a hands-free two-way audio communication system along with full color video and proximity entry. It uses a 125KHz proximity card reader that is compatible with standard 26-bit Wiegand data. A blue LED provides a clear, eye-catching visual indicator to locate the phone and indicate its status.

The compact size of the E-75-EWP allows it to be flush mounted in a standard double gang electrical box. If required, it can be surface mounted using Viking’s VE-5×5 Series Surface Mount Boxes. It is equipped with Enhanced Weather Protection rated IP66 against water and dust ingress and can withstand all but the most extreme of weather events.

Viking E-75-SS-EWP Entry Phone Quick Specs:

• Power: via telephone line
• Dimensions:
• Faceplate: 4.875 x 4.938 x 0.17
• Phone: 2.84 x 1.8 x 1.65
• Operating Conditions: -30° to 150° F
• Speaker Volume: approx. 62db max. @ 3ft
• Ring Voltage: 25V AC RMS min.
• CPC Disconnect: 300ms min. time
• REN: 0.8A
• Connections: 2x gel-filled butt connectors

Viking Electronics E-75-SS-EWP Door Phone Package Contents:

• Viking E-75-SS-EWP phone
• Faceplate in stainless steel
• LED light pipe
• 4x 6-32 x 1.25 long 5/64 hex drive flathead screws
• 1/4"-thick foam faceplate gasket
• Circuit board mounting plate
• 2x gel-filled butt connectors
• 2x junction box to double gang adapter plates
• 4x 5/64 hex drive flathead screws

Viking E-75 Series Documentation:

• Viking E-75 Series Product Manual
