Axis Q6300-E 4x 5 MP 360° Panoramic IP Camera - 02943-001

Axis Q6300-E is a panoramic IP camera that provides 360° coverage by integrating four 5 MP cameras, each with its own 1/2-inch sensor, into one device. Designed to be used with a compatible Axis PTZ Camera from the Axis Q61, Q63, or P56-E Series (not included), Q6300-E and the PTZ camera combine for complete surveillance either indoor or outdoors. You get general coverage and can pick out the important details. Even better, Q6300-E features directional audio detection and autopilot, which lets it point the PTZ camera to the source of an incident immediately. The large camera sensors not only improve detail and provide a better image, but also make the camera ultra-sensitive in low-light conditions, giving you enhanced video all the time. If you want to adjust the field of view to fit different scenes, the camera is compatible with a range of Axis M14 lenses (not included)

Q6300-E is powered by dual ARTPEC-8 Systems on a Chip, which are purpose-built to drive professional security cameras and have a deep learning processing unit. That means the camera can run advanced analytics on the edge. Q6300-E comes with Object Analytics, Video Motion Detection, and Scene Metadata. It also is ultra-secure because of Axis Edge Vault, a hardware-based cybersecurity platform, and secure FIPS 140-2 Level 2 certified key storage. Q6300-E is simple to install, because it has a USB port for use with a compatible Wi-Fi dongle, plus autofocus and auto-alignment functionality, greatly reducing the need for hands-on manipulation. Q6300-E is an outdoor-rated IP camera with, according to NEMA TS 2 (2.2.7), a maximum operating temperature of 165°F and a minimum operating temperature, when connected to an Axis High PoE 120 W power source, of -58°F.

Note: Axis Q6300-E is designed to be used with compatible Axis Q61, Q63, or P56-E Series PTZ Cameras (not included). When used with a P56-E Series Camera, the TP6902-E Adapter Bracket (not included) is required. If you wish to use Q6300-E as an independent 360° panoramic camera, the TQ6812-E Solo Kit (not included) is required.

© 2025 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis Q6300-E Quick Specs:

• System on a Chip (SOC): 2x ARTPEC-8
• Image Sensor: 4x 1/2-in progressive scan RGB CMOS
• Video Resolution: up to 4x 5 MP (2592 x 1944 px)
• Frame Rate: up to 30 fps
• Video Compression: H.264 (AVC) Baseline, Main, High; H.265 (HEVC) Main; Motion JPEG
• Lens: 4x fixed 3.7 mm, f/2.0
• Field of View:
• Horizontal: 360° (108.4° for each sensor)
• Vertical: 84°
• Camera Adjustment:
• Pan: ±180°
• Tilt: -40° to +75°
• Rotation: ±95°
• Minimum Illumination:
• Color: 0.06 lux
• B/W: 0.03 lux
• Physical Connectors:
• Ethernet: Gigabit RJ45 PoE
• USB: for compatible Wi-Fi dongle
• Power Over Ethernet (PoE): up to Axis High PoE 120 W
• Edge Storage: microSD, microSDHC, microSDXC
• ONVIF Profiles: G, M, S, T
• Operating Temperature: -58°F to 131°F
• Durability Ratings: IP66, IK10, NEMA 4X

Axis Q6300-E Panoramic Network Security Camera Package Contents:

• Camera
• Adapter Bracket
• Installation Guide
• Owner Authentication Key

Axis Q6300-E Documentation:

• Axis Q6300-E Datasheet
• Axis Q6300-E Installation Guide
