Fanvil i12 SIP Intercom, 1 Button

Fanvil i12 is a SIP intercom with a Broadcom chipset and a rugged aluminum casing. Rated IP65 and IK10 against the elements, Fanvil i12 brings wideband audio to the outdoor entry phone. Fanvil i12 supports SIP, making it broadly interoperable with VoIP paging systems. It is compatible with many platforms, including 3CX, BroadSoft, Asterisk, Xorcom, and Huawei. Because i12 is a VoIP intercom, managing it and programming it is simpler.

Fanvil i12 features advanced technology, including environmental noise reduction and rich, wideband audio via the 2W speaker, to offer a premier entry phone experience. With dual Ethernet ports and PoE support, it integrates with your network seamlessly. Fanvil has built in vandal protection, as well, including anti-stamp nets and an anti-tamper switch. Fanvil i12 has an incredible operating temperature range of -40°F to 158°F.

Fanvil i12 Quick Specs:

• Connectivity: VoIP
• Communications Protocol: SIP
• SIP Lines: 2
• Ethernet Port: 2x 10/100
• PoE: 802.3af
• Additional Interfaces:
• DC power input
• External active speakers
• Audio recording output
• DSS key
• Short circuit output control
• Short circuit input detection
• Tamper switch
• Status indicator light
• Speaker: 2W, 4Ω
• Audio Codecs: G.711μ/a, G.723.1, G.726-32, G.729AB, G.722
• Operating Temperature: -40°F - 158°F
• Ratings: IP65, IK10

Fanvil i12 Rugged VoIP Intercom Package Contents:

• i12 intercom
• Connector
• Installation diagram
• Quick installation guide
• Installation size map
• Screw and tool
• CD

Fanvil i12 Intercom Documentation:

• Fanvil i12 Datasheet
• Fanvil i12 User Manual
• Fanvil i12 Quick Installation Guide
• Fanvil i12 Mounting Dimensions
