The Viking C-500 entry controller can connect to two lines and offers features including call forwarding and door strike activation. Connect up to two entry phones to the controller, with a five-number auto dialer. The controller can ring other numbers when the primary number is busy or unavailable. Use the controller to activate a door strike and provide entry to guests and visitors.
Compatible with the Viking E-10A, E-20B, E-30, E-35, E-40, E-50, E-60, E-65, E-70 and E-75 entry phones. Also ready for the Viking K-1500-7 phone, K-1700-3 and K-1705-3 phones with keypads, and K-1900-8 phone with keypad.
Viking C-500 Entry System Quick Specs:
- Phones/Lines Supported: 2
- Door Strikes Supported: 2x NO/NC
- Dialer: up to 5 numbers
- Keyless Entry Codes: 6
- Ring Output: 5 REN, up to 10x 0.5 REN phones
- Connections: 19x cage clamp screw terminals
- Dimensions: 5.25” x 4.1” x 1.75”
- Stackable: yes
Viking Electronics C-500 Entry Controller Package Contents:
- Viking C-500 module
- 13.8V AC adapter
