Aiphone IX-DVF-4A 4-Button IP Video Door Station

Aiphone IX-DVF-4A is a vandal-resistant, outdoor IP door station with 4 call buttons and a built-in HD camera. IX-DVF-4A has a 1.23 MP camera to see who's at the door for additional security. Store video and audio using a microSD card or stream it to a network-connected device. Adjust the camera angle vertically to improve the picture. It has four call buttons that you can program to call extensions. There are an additional two trigger inputs for actions like answering a page, as well as two contact outputs for door strike release and other functions.

Aiphone IX-DVF-4A runs SIP. The intercom's faceplate is built out of stainless steel. IX-DVF-4A is designed to be flush-mounted. It is IK08 rated against impacts and IP65 rated against the elements with an extended operating temperature range. It comes with four tamper-resistant security screws. It is ONVIF Profile S compliant, making it interoperable with a broad selection of third-party systems. Power the door phone using PoE.

© 2022 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Aiphone IX-DVF-4A Quick Specs:

• Communications Protocol: SIP
• Camera: 1/3" CMOS 1.23 MP
• Vertical Adjustment: +15°, 0°, -8° (manual)
• Physical Interfaces:
• Ethernet: 1x 10/100 RJ45 PoE
• I/O: 2x contact outputs, 2x trigger inputs
• SD Card: 1x microSD card slot
• PoE: 802.3 af Class 0
• ONVIF: Profile S
• Durability Ratings: IP65, IK08
• Operating Temperature: -40°F to +140°F

Aiphone IX-DVF-4A IP Video Door Station Package Contents:

• IX-DVF-4A Door Station
• Flush Mount Backbox and Mounting Bracket
• 2x Security Screws
• 4x Bracket Screws
• Security Driver
• Door Release Wire Harness

Aiphone IX-DVF-4A Documentation:

• Aiphone IX-DVF-4A Datasheet
