Axis D2123-VE 270° Radar Black - 03125-001

Axis D2123-VE is a radar that delivers AI-powered accuracy across its 270° horizontal field of detection. D2123-VE uses AI to improve classification in large, open, outdoor areas, giving you protection in any weather or lighting conditions, 24/7. The radar has a three box-shaped recognition zone design, which enables effective radar monitoring on in three directions. D2123-VE has a maximum human recognition range of over 450 feet and a maximum vehicle recognition range of over 650 feet, which translates to a recognition zone for humans of up to 320,000 square feet and a recognition zone for vehicles of up to 635,000 square feet. And it accurately tracks up to 100 different objects at the same time, so it truly covers that whole area. Configure D2123-VE to automatically trigger actions on connected devices: set off a strobe/siren, start recording on a camera, and more.

D2123-VE can be used by itself or it can be integrated with select Axis PTZ cameras that use the ARTPEC-9 chip. When used for radar/video fusion surveillance, the system improves data, makes actionable insights better, and simplifies decision making. Configure it so both radar and camera must verify detection and classification before an action is triggered. And only one IP address is required for both devices when paired. D2123-VE streamlines installation by using the same mounting interface as the camera and by its network interface: it connects via Ethernet cable, is powered via PoE, and has a PoE output port for powering the connected PTZ camera. The radar is built for power efficiency to save you on energy costs. Mount D2123-VE on poles, fence lines, or walls (may require a separate mounting kit).

Note: Axis D2123-VE is available in white or black. Axis 03125-001 is the black version. For the white version, see Axis 03126-001.

© 2026 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis D2123-VE Quick Specs:

• Radar Sensor: FMCW (Frequency Modulated Continuous Wave)
• Field of Detection: 270° horizontal
• Recognition Zone: up to 450 ft (for persons)
• Detection Range: up to 650 ft (for vehicles)
• Radar Coverage:
• For Persons: 320,000 ft²
• For Vehicles: 635,000 ft²
• System on Chip (SoC): ARTPEC-9
• Ethernet Ports: 1x Gigabit RJ45 PoE in, 1x Gigabit RJ45 PoE out
• PoE Input: 802.3bt Type 2 Class 4
• PoE Output: 802.3bt Type 4 Class 8 (provides 802.3bt Type 3 Class 6)
• Edge Storage: microSD, microSDHC, microSDXC
• Operating Temperature Range: -40°F to 140°F
• Durability Standards: IP66/IP67, IK10, NEMA 4X
• ONVIF Profiles: G, M, S, T

Axis D2123-VE Radar Black Package Contents:

• Radar
• Installation Guide
• Torx T20 Screwdriver
• Connector Guard
• Cable Gaskets
• Owner Authentication Key

Axis D2123-VE Documentation:

• Axis D2123-VE Datasheet
• Axis D2123-VE Installation Guide
