Axis Q3839-PVE Panoramic IP Camera - 02657-001

Axis Q3839-PVE is an outdoor-ready surveillance camera that seamlessly stitches together feeds from its four lenses, each with its own sensor, to create a single 180° panoramic video feed with minimal distortion. That makes it a 29 MP multi-sensor camera with one IP address — unbelievable detail while making deployment simple and cost-efficient. Gain complete situational awareness using Q3839-PVE with lossless zooming and horizon straightening. Forensic WDR delivers up to 120 dB of contrast compensation, retaining necessary detail in areas that would be lost in shadow or blown out with most other cameras.

Q3839-PVE is powered by two purpose-built Axis ARTPEC-8 Systems on a Chip (SOC). This power not only enables the incredible image stitching, but also a deep selection of AI-driven analytics, including the preinstalled Axis Object Analytics, which automatically detect, classifies, tracks, and counts humans and vehicles. Q3839-PVE also was designed with its own and your network's security in mind: Axis Edge Vault, a hardware-based cybersecurity solution. Stream and/or store video through the network, or store video in camera using a microSD card. Power the camera using PoE. Q3839-PVE is a highly durable camera, meeting the IP66/IP67 and IK10 Standards; it meets the NEMA TS 2 (2.2.7) Standard for operation in temperatures up to 165°F. Q3839-PVE is ONVIF Profile G, M, S, and T Compliant.

© 2026 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis Q3839-PVE Quick Specs:

• Systems on a Chip (SOC): 2x ARTPEC-8
• Image Sensors: 4x 8.3 MP 1/1.8-in progressive scan RGB CMOS
• Video Resolution: up to 7552 x 3776 px
• Frame Rate: up to 30 fps
• Video Compression: H.264 (AVC) Baseline, Main, High; H.265 (HEVC) Main; Motion JPEG
• Lenses: 4x fixed 4.6 mm, f/1.8
• Field of View:
• Horizontal: 180°
• Vertical: 90°
• Camera Adjustment:
• Pan: ±176°
• Tilt: 30° to 88°
• Roll: ±7°
• Minimum Illumination:
• Color: 0.1 lux
• B/W: 0.03 lux
• Audio: configurable duplex
• Physical Connectors:
• Ethernet: Gigabit RJ45
• Audio: 3.5 mm mic/line in
• I/O: terminal block for 1 configurable supervised inputs / digital outputs
• Power: 802.3at Type 2 Class 4 PoE (up to 19.1 W)
• Edge Storage: microSD, microSDHC, microSDXC
• ONVIF Profiles: G, M, S, T
• Operating Temperature: -40°F to +122°F
• Durability Ratings: IP66/IP67, IK10, NEMA 4X

Axis Q3839-PVE Panoramic Camera Package Contents:

• Camera
• Weathershield
• Installation Guide
• Drill Template
• Connector Guard
• Cable Gaskets
• Conduit Adapter
• I/O Connector
• Owner Authentication Key

Axis Q3839-PVE Documentation:

• Axis Q3839-PVE Datasheet
• Axis Q3839-PVE Installation Guide
• Axis Q3839-PVE Dimension Drawing
