Viking E-30-IP Flush-Mount IP Entry Phone

The Viking E-30-IP entry phone is SIP compatible for use with select third-party VoIP phone systems. Connect the phone to your network through a single Ethernet cable, which can also provide PoE. VoIP eliminates the need for a push to talk button. Mount this phone as a speakerphone outside of a critical entry way or access point.

Use the additional connectors on the Viking E-30-IP phone for peripherals and components like LED, help switch, info switch, speaker, microphone and doorstrike/magnetic lock. The phone is designed to be flush mounted, with the optional VE-5x5 supporting surface mount installations. The phone includes a plastic rough-in box for flush mounting. The phone cannot be mounted to a standard double gang box.

Viking E-30-IP Entry Phone Quick Specs:

• Connectivity Type: IP/VoIP
• Communications Protocol: SIP
• Ethernet Ports: 1x 10/100
• PoE: 802.3af Class 1
• Additional Interfaces: 3x gel-filled butt connectors
• Sound Pressure: up to 90dB SPL @ 1m
• Audio Codecs: G.711¼/a, G.722
• Temperature Range: -40°F - 140°F

Viking Electronics E-30-IP Door Entry Phone Package Contents:

• Viking E-30-IP Entry Phone
• Faceplate Gasket
• Torx T-10 Security Bit
• 6-32 x 0.75" Flat Head Torx Drive Screws
• Gel-Filled Butt Connectors
• Flush Mount Back Box

Viking E-30 IP Series Documentation:

• Viking E-30 IP Series Product Manual
• Viking E-30 IP Series Quick Start Guide
• Viking VoIP Compatibility Guide
