Axis P3947-R M12 3.6 mm 5 MP Indoor Onboard IP Camera - 03381-001

Axis P3947-R is purpose-built for HD video surveillance in trains, trams, and similar vehicles and rolling stock. Intended for indoor installation, P3947-R delivers 5 MP resolution video, giving you the precise detail you need for first-class protection, plus it has a built-in microphone to add an audio layer, which can help improve the efficacy of the video evidence. It can take video at up to 60 fps (frames per second) at 1080p Full HD resolution, perfect for the fast-movement scenarios common in transportation. This model of P3947-R has a 3.6 mm lens and M12 connector. The camera is compliant with transportation industry regulations like EN 50155 and EN 45545. It is IP66/67 and IK10 Rated for durability.

P3947-R is an AI-powered camera that uses advanced features to enhance the video quality without you needing to do a thing. Lightfinder 2.0 technology delivers accurate color reproduction even in extreme low-light; Forensic WDR technology retains detail during high-contrast lighting where otherwise the image would be under- or overexposed. To help you obtain the optimal video for the specific use-case, Axis developed scene profiles that you can choose from, including forensic, vivid, and traffic overview. P3947-R is built to be secure: it is protected by Axis Edge Vault, a hardware-based cybersecurity platform. The platform includes FIPS 140-3 Level 3 certified secure key storage and more. You can store HD video in camera using a microSD card. P3947-R matches earlier Axis onboard cameras in form-factor, backplate, and accessories, which makes it very easy to upgrade to this improved model and gain audio pickup, advanced video features, and more.

Note: Axis P3947-R is available in four variants: with either a 2.8 mm or 3.6 mm lens, and with either an RJ45 or M12 connector. This model, Axis 03381-001, has a 3.6 mm lens and M12 connector.

© 2026 IP Phone Warehouse. All rights reserved, including the right to reproduce this product description or portions thereof in any form whatsoever.

Axis P3947-R M12 3.6 mm Quick Specs:

• System on a Chip (SoC): CV75
• Image Sensor: 1/2.8-in progressive scan RGB CMOS
• Video Resolution: up to 5 MP (2560 x 1440 px)
• Frame Rate: up to 30 fps (with WDR); up to 60 fps (1920 x 1080 px resolution without WDR)
• Video Compression: H.264 (AVC) Main, High; H.265 (HEVC) Main; Motion JPEG
• Lens: fixed 3.6 mm, f/2.0
• Field of View:
• Horizontal: 83°
• Vertical: 60°
• Camera Adjustment:
• Pan: ±30°
• Tilt: 0° to 90°
• Rotation: -179° to 180°
• Minimum Illumination:
• Color: 0.16 lux
• Microphone: built-in microphone (can be disabled)
• Hardware Interfaces:
• M12: female, rugged, D-coded with rotatable coupling nut
• Power: 802.3af Type 1 Class 2 PoE (typical 3.55 W; max. 4.42 W)
• Storage: microSD, microSDHC, microSDXC
• ONVIF Profiles: G, M, S, T
• Operating Temperature Range: -22°F to 131°F
• Durability Ratings: IP66/67, IK10, NEMA 4X

Axis P3947-R M12 3.6 mm Dome Camera Package Contents:

• Camera
• Installation Guide
• Windows Decoder 1-User License
• Lens Tool

Axis P3947-R Documentation:

• Axis P3947-R Datasheet
• Axis P3947-R Installation Guide
• Axis P3947-R Dimension Drawing
